Toshiba BTH 130.R16 CNC boring machine
Model: BTH 130.R16 Age: 2013
Tosnac 999 4-axis ed CNC control
90 station automatic tool changing machine
Built in full B-axis rotating table
(2) 1400MM x 1600MM tray,
Dual station shuttle system
Renishaw detector
Full chip and sputtering shell
Specifications:
Spindle diameter 130 millimeters
Spindle cone # 50
Vertical travel, Y-axis 2096mm
Cross travel, X-axis 2540 MM
Spindle travel, Z-axis 711 millimeters
Column travel, W-axis 1524 millimeters
Table index B axis 0.001 degrees
Spindle speed (3rd gear) 6-4000 revolutions per minute
Spindle motor 30 HP/30 KW
Quick Rail 393.70 IPM
Feed. 04-141 IPM
equipment:
Equipped with shuttle system
Cross flow shaft coolant
Full chip and sputtering shell
Renishaw detector
Chip conveyor
